This 3-in-1 optical multimeter is a compact and easy-to-use testing instrument for optical fiber networks and is composed of optical power meter optical light source Visual fault locator.It can be used for measuring levels and loss in fiber networks quickly, easily, and conveniently. It is also equipped with a light source as well as VFL for optical fiber winding or breakage.It has a wide range of power measurements and has a high accuracy with high performance-to-price ratio.Features• Testing instrument for optical fiber networks, which can be used for absolute optical power measurements as well as for relative loss measurements in optical fibers. • Six Wavelengths for single mode & multi mode: 850/ 1300/1310/1490/1550/1625nm. • Light Source Function • FC/SC/ST general-purpose interface • Insertion loss test of optical devicesSpecifications• Detector Type: IngaAs • Measurement Range(dBm): -50~ 26 • Uncertainty: 3% • Calibrated wavelengths(nm): 850, 1300, 1310, 1490, 1550, 1625nm • Resolution (dB): 0.01dBm • Identification Frequency Range: 10Hz~60KHz • Optical Connector: FC (SC,ST,LC connector can be optional)Optical Light Source Module• Emitter Type: FP-LD • Wavelengths: 1310/1550(other wavelengths can be optional) • Ouput Power(dBm): -7dBm • Output Stability: ±0.05dB/15mins; ±0.1dB/ 8hours • Modulation Frequencies: 270Hz, 1KHz, 2KHz • Optical Connector: FC (SC,ST,LC connector can be optional)Visual fault locator• Emmiting Energy: 5mw / 10mw / 20mw / 30mw Selectable • Standard wavelenth: 650±10nm • Operation Mode: Pulsed (2Hz) and CW • Connector: 2.5mm or 1.25mm Universal connectorGeneral Specifications of Multi Meter• Auto-off time: 15mins • Operating Temperature(°C): -10~ 60 • Storage Temperature(°C): -25~ 70 • Dimension(mm): 160x75x32mmSet includes1 x 3 in 1 Professional Optical Multimeter 1 x Instruction Manual 1 x Case SKU: 277 Categories: Cable Testers, Fibre Tester Brand: AZInstruments
